1.Adopt spur gear transmission,after carburizing and quenching treatment,tooth to tooth wide practice treatment,surface sandblasting and nickel plating,stable operation of equipment,low noise.

2.Simple structure,fast delivery time,mass production.

3.There are a variety of reducer,which can meet most of the working conditions in the market.

TVD列性能參數表 / TVD Series Performance Table
規格 Specification	單位 Unit	節數Stage	減速比Ratio	TVD60	TVD90	TVD120	TVD160	TVD200
額定輸出力矩Rated output torqueT_2N	Nm	1	3	42	142	284	568	1136
			4	42	147	294	588	1176
			5	42	147	294	588	1176
			6	42	147	294	588	1176
			7	33	99	198	396	792
			8	39	97	195	389	778
			10	15	53	105	210	420
		2	15	28	111	267	534	1068
			20	42	147	294	588	1176
			25	42	147	294	588	1176
			30	42	147	294	588	1176
			35	42	147	294	588	1176
			40	42	147	294	588	1176
			50	42	147	294	588	1176
			60	42	147	294	588	1176
			70	33	99	198	396	911
			80	33	99	198	396	911
			100	15	53	105	315	725
		3	64	42	147	294	588	1352
			80	42	147	294	588	1352
			100	42	147	294	588	1352
			150	42	147	294	588	1352
			200	42	147	294	588	1352
			250	42	147	294	588	1352
			350	42	147	294	588	1352
			400	42	147	294	588	1352
			500	42	147	294	588	1352
			700	33	99	198	396	990
			1000	15	53	100	299	868
急停扭矩 / Emergency stop torqueT_2NOT	Nm	1,2,3	3 ?1000	二倍額定輸出力矩 / Triple rated output torque
額定輸入轉速 / Rated input speed η_1N	rpm	1,2,3	3-1000	5000	4000	4000	3000	3000
******輸入轉速 / Maximum input speed η_1B	rpm	1,2,3	3-1000	10000	8000	8000	6000	6000
扭轉剛性 / Torsional rigidity	Nm/arcmin	1,2,3	3-100	7	14	25	50	145
容許徑向力 / Allowable radial force F_2aB	N	1,2,3	3-1000	1530	3250	6700	9400	14500
容許軸向力 / Allowable axial force F_2aB	N	1,2,3	3-1000	765	1625	3350	4700	7250
使用壽命 / Lifespan	hr	1,2,3	3-1000	20000
效率 / Efficiency	%	1	3?100	≥97%
	%	2,3	15 ~ 1000	≥94%
重量 / Weight	kg	1	3~10	1.4	3.7	7.3	21	35
		2	15 ?100	1.6	4.1	9	26	40
		3	64-1000	1.8	4.8	11.2	31	45
使用溫度 / Working temperature	°C	1,2,3	3-1000	-10°C~90°C
潤滑 / Lubricating		1,2,3	合成潤滑油脂 / Synthetic lubricating grease
防護等級 / IP Grade		1,2,3	3-1000	IP65
安裝方向 / Installation direction		1,2,3	3-1000	任意方向 / In any direction
噪音值(n1=3000rpm,無負載) Noise level (η1=3000rpm,off load)	dB(A)	1,2,3	3 ?100	≤58	≤60	≤63	≤65	≤65
