1.Adopt spur gear transmission,after carburizing and quenching treatment,tooth to tooth wide practice treatment,surface sandblasting and nickel plating,stable operation of equipment,low noise.

2.Simple structure,fast delivery time,mass production.

3.There are a variety of reducer,which can meet most of the working conditions in the market.

TVB系列性能參數表 / TVB Series Performance Table
規格 Specification	單位 Unit	節數Stage	減速比Ratio	TVB60	TVB90	TVB120	TVB142	TVB180
額定輸出力矩Rated output torqueT_2N	Nm	1	3	46	135	270	486	1312
			4	46	162	324	648	1621
			5	46	162	324	648	1621
			6	46	162	324	648	1621
			7	39	136	272	545	1362
			8	39	136	272	545	1362
			10	19	65	162	324	809
		2	15	28	97	234	560	1345
			20	46	162	324	648	1621
			25	46	162	324	648	1621
			30	46	162	324	648	1621
			35	46	162	324	648	1621
			40	46	162	324	648	1621
			50	46	162	324	648	1621
			60	39	136	272	545	1362
			70	39	136	272	545	1362
			80	39	136	272	545	1362
			100	19	65	155	373	895
		3	64	46	162	324	648	1621
			80	46	162	324	648	1621
			100	46	162	324	648	1621
			150	46	162	324	648	1621
			200	46	162	324	648	1621
			250	46	162	324	648	1621
			350	46	162	324	648	1621
			400	46	162	324	648	1621
			500	46	162	324	648	1621
			700	39	136	272	545	1362
			1000	19	65	130	259	648
急停扭矩 / Emergency stop torqueT_2NOT	Nm	1,2,3	3 ?1000	二倍額定輸出力矩 / Triple rated output torque
額定輸入轉速 / Rated input speed η_1N	rpm	1,2,3	3-1000	5000	4000	4000	3000	3000
******輸入轉速 / Maximum input speed η_1B	rpm	1,2,3	3-1000	10000	8000	8000	6000	6000
扭轉剛性 / Torsional rigidity	Nm/arcmin	1,2,3	3-100	7	14	25	50	145
容許徑向力 / Allowable radial force F_2aB	N	1,2,3	3-1000	1530	3250	6700	9400	14500
容許軸向力 / Allowable axial force F_2aB	N	1,2,3	3-1000	765	1625	3350	4700	7250
使用壽命 / Lifespan	hr	1,2,3	3-1000	20000
效率 / Efficiency	%	1	3?100	≥97%
	%	2,3	15 ~ 1000	≥94%
重量 / Weight	kg	1	3~10	1.3	3.7	7.8	14.5	28
		2	15 ?100	1.5	4.1	9	17.5	32
		3	64-1000	1.8	4.8	11.2	24	36
使用溫度 / Working temperature	°C	1,2,3	3-1000	-10°C~90°C
潤滑 / Lubricating		1,2,3	合成潤滑油脂 / Synthetic lubricating grease
防護等級 / IP Grade		1,2,3	3-1000	IP65
安裝方向 / Installation direction		1,2,3	3-1000	任意方向 / In any direction
噪音值(n1=3000rpm,無負載) Noise level (η1=3000rpm,off load)	dB(A)	1,2,3	3 ?100	≤58	≤60	≤63	≤65	≤65
