1.Adopt spur gear transmission,after carburizing and quenching treatment,tooth to tooth wide practice treatment,surface sandblasting and nickel plating,stable operation of equipment,low noise.

2.Simple structure,fast delivery time,mass production.

3.There are a variety of reducer,which can meet most of the working conditions in the market.

TAE系列性能表 / TAE Series Performance Table
規格 Specification	單位 Unit	節數 Stage	減速比 Ratio	TAE070	TAE090	TAE120	TAE155	TAE205
額定輸出力矩 Rated output torque T_2N	Nm	1	3	55	130	208	342	588
			4	50	140	290	542	1050
			5	60	160	330	650	1200
			6	55	150	310	600	1100
			7	50	140	300	550	1100
			8	45	120	260	500	1000
			10	40	100	230	450	900
		2	15	55	130	208	342	588
			20	50	140	290	542	1050
			25	60	160	330	650	1200
			30	55	150	310	600	1100
			35	50	140	300	550	1100
			40	45	120	260	500	1000
			50	60	160	330	650	1200
			60	55	150	310	600	1100
			70	50	140	300	550	1100
			80	45	120	260	500	1000
			100	40	100	230	450	900
急停扭矩 /Emergency stop torque T_2NOT	Nm	1.2	3-100	三倍額定輸出力矩/Triple rated output torque
額定輸入轉速/Rated input speed η1N	rpm	1,2	3-100	5000	4000	4000	3000	3000
******輸入轉速/Maximum input speed η1B	rpm	1,2	3-100	10000	8000	8000	6000	6000
扭轉剛性 /Torsional rigidity	Nm/arcmin	1,2	3-100	7	14	25	50	145
容許徑向力 /Allowable radial force F_2aB	N	1,2	3-100	1530	3250	6700	9400	14500
容許軸向力/Allowable axial force F_2aB	N	1,2	3-100	765	1625	3350	4700	7250
使用壽命/Lifespan	hr	1,2	3-100	20000
效率 /Efficiency	%		3?10	≥97%
效率 /Efficiency	%	2	15-100	≥94%
重量 /Weight	kg		3~10	1.4	3.7	8	16	36
重量 /Weight	kg	2	15-100	1.6	4.2	8.9	17	37
使用溫度 /Working temperature	°C	1,2	3-100	-10°C~90°C
潤滑 /Lubricating		1,2		合成潤滑油脂 /Synthetic lubricating grease
防護等級/IP Grade		1,2	3-100	IP65
安裝方向 /Installation direction		1,2	3-100	任意方向/In any direction
噪音值(η1 =3000rpm,無負載) Noise level (η1 =3000rpm,off load)	dB(A)	1,2	3-100	≤58	≤60	≤63	≤65	≤67
